Special Filters for Plastic: Improving Quality and Reducing Production Costs
Plastic filtration is a crucial process to ensure the quality of final products and to prevent defects during production.
Special filters are a fundamental component of plastic filtration systems, as they continuously remove impurities and contaminants from plastic materials during the manufacturing process.
Modestino Filtri S.r.l.s. is a leading company, recognized nationally and internationally, specializing in the production of special filters made of iron and stainless steel (AISI 304) for all types of extruders.
THE BEGINNING OF A NEW ERA!
FR-REVERSE
*Forged-Reverse*
All Modestino reverse metal meshes are designed to meet the ever-evolving demands of the plastic recycling market.
The wires that make up the reverse metal mesh are hot-dip galvanized, resulting in an aesthetically polished and shiny appearance.
Thanks to heat treatment (TEMPERING), the mesh becomes 60% stiffer compared to non-tempered standards of the same type.
3-E POWER
ECONOMICAL, EFFECTIVE, ESSENTIAL
80µm
FR-110/22
-Nominal filtration 80µm.
-Wires: 0.22mm/0.35mm
Head pressure ≠ 250Bar
100µm
FR-110/17
-Nominal filtration 100µm.
-Wires: 0,22mm/0,35mm
Head pressure ≠ 250Bar
125µm
FR-110/15
-Nominal filtration 125µm.
-Wires: 0,22mm/0,35mm
Head pressure ≠ 250Bar
160µm
FR110/13
-Nominal filtration 160µm.
-Wires: 0,22mm/0,35mm
Head pressure ≠ 250Bar
200µm
FR-110/10
-Nominal filtration 200µm.
-Wires: 0,22mm/0,45mm
Head pressure ≠ 250Bar
300µm
Reverse Fabric SPG
-Nominal filtration 300µm.
-Wires: 0,22mm/0,45mm
Head pressure ≠ 250Bar
